PRODUCT DETAILS
PPRODUCT DETAILS
THR-V5600
0.00
0.00
Features:
Powerful Data Management:
Rapidly retrieve the image data management function
Internal work station mult-plan template: realize process mult medical histories function,quickly finish data, report etc.
• Big display zone for large image size, with high quality.
• Professional software for small animals.
• Fast one-key
operation: one-key storage,browse, etc.
operation: one-key storage,browse, etc.
• I-Station integral workstation,connect with network, one-key print.
• Built-in workstation templates:multi-case management, rapid data & report management.
Reasonable Humanization Design:
10.4' color LED full screen display, angle adjustment
Rapidly one-key operation incudes one-key storage one-key browse and one-key print
Large-capacity lithum battery can drive the main unit to work more than 200 minutes
Internal 4G C disk storage capacity, permannent 5000 frames image, without loss when power off
10.4' color LED full screen display, angle adjustment
Rapidly one-key operation incudes one-key storage one-key browse and one-key print
Large-capacity lithum battery can drive the main unit to work more than 200 minutes
Internal 4G C disk storage capacity, permannent 5000 frames image, without loss when power off
Powerful Data Management:
Rapidly retrieve the image data management function
Internal work station mult-plan template: realize process mult medical histories function,quickly finish data, report etc.
Manage function
1-Station integral work satation, connect to network, realize one- key print
Abundant Software Package:
OB measurement : GA and EDD for swine, bovine, canine, equine, feline,goat, lama and ovine
Other measurement: Calculate lean percentage of swine
OB report function
1-Station integral work satation, connect to network, realize one- key print
Abundant Software Package:
OB measurement : GA and EDD for swine, bovine, canine, equine, feline,goat, lama and ovine
Other measurement: Calculate lean percentage of swine
OB report function
Specification
Language | Spanish, English, French, Russian and Portuguese |
Sockets | Two probe sockets, auto-identify different optional probe |
Body marks | 1. General 2. Bovine 3.Canine 4.Equine 5.Feline 6.Cardio 7.Swine, total 27 kinds body marks indicating probe position； |
Display mode | B、2B、4B 、B/M、M |
Adjustable depth | 10 grades, max depth to 236mm |
Gain | 0～127dB |
Contrast | 27～90dB |
Gray scale | 256 |
8 steps intelligent TGC | 8 kinds pseudo colors |
Image storage | 4G hard disk to permanently store about 5000 frames images |
Cine loop | 256 frames |
Puncture guide function with 2 correctable puncture guiding lines(adjustable angle & position) | The gravel software package with real-time position line measuremen |
Normal measurement | Distance, circumference, area (Trochoid or ellipse), volume, etc. |
Cardio measurement | Depth, slope, heart rate, cycle |
OB measurement | Bovine, Canine, Equine, Feline, Ovine, Camels and Swine and pre-gestational age birth； |
Other measurement | Pig’s meat factor measurement |
Standard Configuration | Optional Configuration |
Main unit: 1pc | Optional probes： 6.5MHz linear rectal probe 3.5MHz linear probe for eye muscle 3.5MHz convex probe 7.5MHz linear probe |
6.5MHz micro-convex probe：1pc | trolley |
Power supply adaptor：1pc | Video printer |
Li-Battery： 1pc | |
Reticle： 1pc | |
Two probe sockets |
