Sample Block

3 blocks 32 wells
0.2 ml PCR tube with flat ＆ dome cap

Heating&Cooling Technology

New generation Peltier technology allow 1,000,000 cycles

Display

10”Full Color Touch Screen with adjustable angle, and real-time graphical display

Language

English

USB flash drive Function

Unlimited storage of protocols with USB flash drive;Back up user’s data

Communication Ports

USB 2.0& LAN

Block Temp.Range

4℃－99.9℃

Max.Heating Rate

7.5℃/s

Max.Cooling Rate

6℃/s

Temp.Uniformity

≤±0.2℃(at90℃)

Temp.Accuracy

≤±0.2℃(at90℃)

Display Resolution

0.1℃

Ramping Rate Adjustable

0.1－5.0℃

Mode of Temp.Control

Block ＆Sim-tube mode

Gradient Accuracy

≤±0.1℃

Uniformity

Wells of Same Line Uniformity≤±0.2℃

Gradient Range

30℃－99.9℃

Temp.Differential Range

The Temp.difference is 1-25℃,the maximum Temp. difference up to 75℃when integrating 3 blocks.

Display of Gradient Temperature

Each individual block has 8 gradient temperatures

Max.Number Of Programs

Max.15,000 programs onboard,unlimited storage of protocols with USB flash drive

Max.Step

30 Steps, multiple nesting cycles available

Max.Cycle

100 Typical Cycles (multiple nesting allows 10,000 cycles)

Time Increment/decrement

1－120 sec, available for Long PCR

Temp.Increment/decrement

0.1－10.0℃, available for Touchdown PCR

Auto Pause ＆Auto Restart

Yes

Hold at4℃

A below ambient Temp. incubation allow PCR products storage overnight

Program Wizard

Pre-program template make the editing very easy through modify several parameters

Running Report

Provide full review of perviously run protocols

Lid Temp.Range

30℃－112℃

Open Method

Innovative TOP-OPEN technology, with even pressure of heat lid.

Auto Shut-off

Lid will shut off automatically when the block Temp. falls below set Temp.

Power

Global switch power supply: 100V-240V, 50-60Hz

Consumption

750W

Dimensions(L×W×H)

375×270×277mm

Net Weight

13KG
