THR-XR-3D
0.00
0.00
Field of View (mm × mm) | 160 × 150, 160 × 80, 80 × 80, 50 × 80 |
Voxel Size (mm) | 0.25, 0.125, 0.1, 0.075 |
Spatial Resolution (lp/mm) | 2.6 |
Reconstruction Time(s) | ≤30 |
Tube Current(mA) | min: 2 max: 10 (60kV) |
Tube Voltage(kV) | min: 60 max: 100 (6mA) |
Scan Time(s) | 13,15,18 |
Focal Spot Size | 0.5(IEC336) |
Sensor Type | CMOS Flat Panel Detector |
Sensor Size(cm) | 13x13 |
Weight(kg) | 340 |
Unit Dimensions(mm) | 1825(D) × 1077(W) × 2109(H) |
Packing Size(mm) | Case 1: 1930×800×1300, 403kg, Case 2: 1970×1270×1170, 290kg |
Power | single-phase, AC220V/230V, ±10%, 10A, 50Hz, ±1Hz |
Clinical Applications
1) Endodontic and Periodontal Examinations
The machine with an image resolution up to 2.6 lp/mm, provides rich and accurate information for the examination of endodontic and periodontal diseases.
2) Root Canal Filling Examinations
With a professional color map and filter, it can clearly identify the orientation, shape and size of a root canal.
Multiple and complex root canal treatments can be easily and accurately observed in 3D
Multiple and complex root canal treatments can be easily and accurately observed in 3D
3) Implant Applications
By using the full oral 3D image generated , we can evaluate the bone density of the implant area, determine the relationship between the implant position and adjacent anatomical structure, finalize the placement, optimize the length and diameter of the implant, improve implant success rate and avoid possible neurovascular damage.
4) Model Scan (optional)
It has a model scan function for scanning impressions and plaster models. Scanning accuracy is up to 100μm. The system can easily export STL 3D digital model files for third-party surgical guides and printing.
5) Post-Implanting Assessment
As the metal artifact correction function is optimized with artificial intelligence, it can more accurately judge the estimation and status of implant position, angle and jaw for the dentist to assess post-implant planting.
6) Temporomandibular Joint Disorders
With the SmartV high resolution 3D image and multi-layer slicing function imaging system, it can display condyle and fossa morphology in extremely clear detail, easily identify erosions, osteophytes and fractures, provide more information for the diagnosis of temporomandibular joint disorders and evaluate the therapeutic effect.
7) Airway Observation
With auto trace function and gradient color display,it can automatically trace the airway, calculate the volume, highlight the narrow area with different color, and calculate the size of the narrowest area for optimal treatment of patients suffering from sleep disorders, sleep apnea, and sinus complications.
