THR-XR-100

THR-XR-100

0.00
0.00


Features:
1. Produced by high-frequency inverter technology, stable high-voltage output can get good image quality;
2. A compact design, easy to carry and work in different regions and locations;
3. There are three exposure control methods: remote control, hand brake and interface buttons;
4. Fault self-diagnosis and self-protection;
5. With a flexible digital interface, users can go deep into the core programming control and can adapt to different DR detectors.

Specification
item
value
Brand Name
THR
Model Number
THR-XR-100
power
5kW
working frequency
≥30kHz
Inverter method
PWM(Pulse width modulation)
Properties
Medical X-ray Equipments & Accessories
photography kv range
40-50KV、40-60KV、 40-80KV、 40-100KV、 40-1 10KV
photography ma range
100mA、80mA、 63mA、50mA、 32mA
mAs range
0. 32-315mAs
exposure time range
0.01-6.3s
working frequency
> 30kHz
host machine size
37*26*23cm
Input power type
220V土10%,50HZ/60Hz
weight
21kg
